Network Cabinets
Outdoor Cabinets
As Sichert’s preferred UK partner, we supply a range of polycarbonate street cabinets designed for flexible network deployments. Available in multiple sizes and configurations, each enclosure can be tailored to project requirements. Manufactured in Europe and configured in our Gloucester warehouse, they deliver reliable performance for critical infrastructure.
SICAB 24 4×19″
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Can be fitted with active or passive components
- 4x 19″/ETS rack (21 units / 38 units)
- Strain relief plates and rails
- Routing elements
- Base plate with rubber grommets for
- 8x Ø 9.5…42 mm, 9x Ø 3…25 mm + 20x cable gland M25
SICAB 24 Ad-Box
- Display up to 3 x 32″ HD video adverts, uploaded and managed remotely
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Can be fitted with active or passive components
- 4x 19″/ETS rack (21 units / 38 units)
- Strain relief plates and rails
- Routing elements
- Base plate with rubber grommets for
- 8x Ø 9.5…42 mm, 9x Ø 3…25 mm + 20x cable gland M25
SiCab 18 OutdoorPOP
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Can be fitted with active or passive components
- 1x 19“/ETS rack (21 U / 38 SU)
- 1x Rack for cable heads (bay 120 mm)
- Back board made of plastic WxH: 600×1000 mm
- Separate energy supplier partition
- Routing elements and strain relief rails
- Base plate with rubber grommets for 48x Ø 9.5…42 mm
- Strain relief (C rail) in lower cabinet part</li
SiCab 15 MiniPOP
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Can be fitted with active or passive components
- 1x 19“/ETS frame (21 U / 38 SU)
- 1x Frame for cable heads with one bay
- Energy supplier partition with power termination unit
- Fiber trays kit on the right side
SICAB 12 2×19″
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Can be fitted with active or passive components
- 2x 19“/ETS rack (21 U / 38 SU)
- Base plate with rubber grommets for 28x Ø 9.5…42 mm
- Strain relief (C rails) in lower cabinet part
SICAB 8 19″
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Can be fitted with active or passive components
- 1x 19“/ETS rack (21 U / 38 SU)
- Base plate with rubber grommets for 18x Ø 9.5…42 mm
FCC3-24/48
- Weather resistant double-walled outdoor cabinet made of glass fibre reinforced polycarbonate
- Delivered with trays and installation kits for micro ducts
- Storage for loose tubes behind the tray module for overlength version
- IN: 6x Ø 12 – 20 mm + 1x Ø 12 – 14 mm, Loop
- OUT: 24/48 x Ø 7 / 10 mm
- Max trays: 54x SC / 27x SE
- Max splices: 648
Uni-Cab Range
- Robust single-walled cabinet for passive applications
- Outer parts are exchangeable without interruption of service
- Predetermined breaking elements for protection of the cabinet
- Various configurations with a wide range of additional equipment options and accessories are available
- 100% recyclable polycarbonate
Cabinet Maintenance
- Visual Inspection – Identify key issues including the supply of a full video inspection
- Security Inspection – Inspection and testing of the cabinet’s locking system, identifying any vulnerabilities and making recommendations
- Electrical Inspection – Full electrical inspection and test report
- Meter Reading – Annual electrical meter reading
- Backup Battery Maintenance – Backup battery testing and capacity report
- General Repairs – Standard maintenance repairs to the cabinet if needed
- Report & Walkaround – Full report with recommendations
- Cabinet Cleanse – Full exterior cabinet clean
Indoor Cabinets
Our indoor cabinet solutions provide secure, organised housing for networking and IT equipment within controlled environments such as data rooms and technical spaces.
Smart Net Cab - Black
A cost effective , stylish and secure enclosure for low to medium weight loads.
- Heights: 12U, 18U, 20U, 25U, 27U, 33U, 39U, 42U, 45U & 47U
- Depths: 600mm, 800mm, 1000mm & 1200mm
- Two widths: 600mm, 800mm
- Load rating: 800kg static (sited directly on floor)
- For lower density cabling via 4 brush gland mouldings within roof corner area
- Available assembled or flat-packed
- 600 & 800 deep variants installed as standard with glass front door and plain vent rear door
- 1000 & 1200 deep variants installed as standard with perforated front & rear door
- Optional split wardrobe style perforated door
Smart Net Cab - Grey
A cost effective , stylish and secure enclosure for low to medium weight loads.
- Heights: 12U, 18U, 20U, 25U, 27U, 33U, 39U, 42U, 45U & 47U
- Depths: 600mm, 800mm, 1000mm & 1200mm
- Two widths: 600mm, 800mm
- Load rating: 800kg static (sited directly on floor)
- For lower density cabling via 4 brush gland mouldings within roof corner area
- Available assembled or flat-packed
- 600 & 800 deep variants installed as standard with glass front door and plain vent rear door
- 1000 & 1200 deep variants installed as standard with perforated front & rear door
- Optional split wardrobe style perforated door
Smart Net Fan Units
- Standard fixing roof mounted fan unit for use with Smart Net Cabinet Enclosure
- 2, 4 and 6 fan option available (230VAC 50Hz 45dB per fan)
- Supplied fitted with 3m mains lead and 13 amp UK plug
- Alternative plug options available including commando and IEC
- Fitted with finger guards
